| Configuration |
| Functions |
Print |
| Colour |
Yes |
| HDD |
320 GB—optional |
| Memory – standard |
2 GB |
| Operation panel |
4-line LCD |
| Physical dimensions |
| Physical dimensions (WxDxH)—mainframe |
410 x 429 x 360 mm |
| Weight—mainframe |
25 kg |
| Media handling |
| Standard input capacity (sheets) |
250 |
| Maximum input capacity (sheets) |
1,300 |
| Standard output capacity (sheets) |
200 |
| Maximum output capacity (sheets) |
200 |
| Paper input configuration – standard |
250-sheet paper input tray, 50-sheet bypass tray, duplex unit |
| Paper output configuration – standard |
200-sheet paper output tray |
| Supported media |
Standard tray
Plain Paper, Recycled Paper, Coloured Paper, Special Paper 1–3, Letterhead, Preprinted Paper, Bond Paper, Cardstock, Label Paper, Backing Paper, Envelope, Coated Paper
Bypass tray
 Plain Paper, Recycled Paper, Colour Paper, Special Paper 1-3, Letterhead, Preprinted paper, Bond Paper, Cardstock, Label Paper, Backing Paper, Envelope, Coated Paper

Optional tray
Plain Paper, Recycled Paper, Coloured Paper, Special Paper1-3, Letterhead, Preprinted Paper, Bond Paper, Cardstock, Label Paper, Backing Paper, Coated Paper |
| Maximum paper size |
A4 |
| Media weight (g/m2) |
60–200 |
| Connectivity |
| Interfaces – standard |
10Base-T/100Base-TX/1000Base-T (Gigabit Ethernet)
USB Host Type A—1 port (for service use only)
USB Device Type B—1 port
SD Card—1 slot
USB Host Type A—1 port (for Media Direct Print) |
| Interfaces – optional |
Wireless LAN (IEEE 802.11 a/b/g/n/ac)
Device Server Option (additional 10Base-T/100Base-TX/1000Base-T port) |
| Network protocols – standard |
TCP/IP (IPv4, IPv6) |
| Print features |
| Print speed colour |
32 ppm—simplex
16 ppm—duplex |
| Print speed black and white |
32 ppm—simplex
16 ppm—duplex |
| First print time |
4.1 seconds—black and white, 5.3 seconds—colour |
| Print resolution |
1,200 x 1,200 dpi |
| Page description languages (PDLs) |
Standard
PCL 6, PostScript3 emulation, PDF Direct emulation
Optional
Adobe PostScript 3, PDF Direct from Adobe  |
| Printer drivers |
Standard
PCL 6, PostScript3 emulation
Optional
Adobe PostScript 3  |
| Duplex printing |
Standard |
| Mobile printing |
Airprint, Mopria®, RICOH Smart Device Connector |
| Print from USB/SD |
Supported—USB only |
| Security features |
| Data Overwrite Security System (DOSS) – Standard |
With optional HDD |
| Encryption |
Machine data encryption
Authentication password encryption
Encrypted secure print
Encrypted PDF Mode |
| Authentication |
802.1x wired authentication
IEEE 802.11 security (WEP, WPA, WPA2, WPA3)
User code authentication
User authentication—Windows, LDAP via Kerberos, basic
Network user authentication |
| Supported operating environments |
| Windows |
10 (32-/64-bit), 11, Server 2016, Server 2019, Server 2022 |
| Macintosh |
MacOS 11 and later |
| Unix |
N/A |
| SAP |
Environment—R/3, S/4
Note: Requires optional Unicode Font Package for SAP |
| Software and Solutions |
| Standard |
@Remote Embedded
Web Image Monitor |
| Optional |
RICOH Streamline NX V3
Device Manager NX Lite
Device Manager NX Accounting
RICOH @Remote Connector NX |
| Mobile apps |
RICOH Smart Device Connector |
