B512dn

A superfast print speed, high monthly duty cycle and large standard paper capacity equips the B512dn to handle high volume printing with ease.

Users: 1 – 15
A4 Print speed: 45ppm
Print Resolution: 1200 x 1200 dpi
Media Handling: A6 to 1.3m banners and up to 163gsm card
Function: 530 sheets paper tray, AirPrint, double side print, optional 2nd paper tray

Category:

This clever printer incorporates automatic double sided printing to help save paper and will optimise its speed and power usage to the type of documents being printed, even powering off overnight. LED technology and the option of extra high capacity toners help reduce running costs. With Gigabit networking as standard the B512dn delivers fast speed, high quality black and white printing for all in the office to share – Perfect for the workgroup.

B432dn Print Sample

Designed for high print volumes

Fast warm-up time, a high speed processor and large memory enables the B512dn to power through high and low volume print jobs with ease. With Gigabit Ethernet as standard and an optional Wireless interface, sharing is made easy.

  • Time to first print in 4.5 seconds
  • A4 print speeds of up to 45ppm
  • 5 second warm-up time from Deep Sleep mode
  • 530 sheet paper tray and 530 sheet 2nd tray option
  • 667MHz processor and 512MB RAM + 3GB eMMc memory
  • PCL/PostScript emulations
  • 10/100/1000 Ethernet
  • Optional Wireless LAN 802.11b/g/n

High quality, versatile printing

The B512dn offers flexible media handling, digital LED print quality and the versatility to meet your businesses needs.

  • From A6 to A4 and banners up to 1.3m long
  • Print on card stock up to 163gsm
  • 1200 x 1200dpi print resolution ensures pinsharp output every time
  • Secure printing protects confidential documents
  • Google Cloud print ready and compatible with AirPrint by Apple inc.
  • Choose the toner size to suit your business needs, 3k, 7k or extra high capacity 12k toner for the lowest running costs

Reliable, ergonomic and easy to use

Simple ergonomic design makes life easy, whilst 3 year warranty provides total peace of mind.

  • Compact, low profile design for ease of use
  • Auto sensing 100 sheet Multi-purpose tray (MPT) for different paper types
  • 2-line x 16-character LCD display for clear, real-time status
  • One click driver installation
  • Three year warranty on registration of your product within 30 days

Powerful features reduce costs and environmental impact

Save paper and power usage whilst reducing your running costs. There is even a noise reduction mode for quieter working environments.

  • Duplex printing as standard, reducing paper usage by printing on both sides
  • Eco mode improves throughput performance and reduces energy consumption
  • Quiet mode reduces noise levels and energy consumption
  • 1.4W Deep Sleep mode and super fast recovery time saves power without impacting performance
  • ‘Auto Power Off’ function saves energy
  • Energy Star 2.0 compliant



DOWNLOAD BROCHURE

B512dn Specification Sheet

OKI Pro Series Range Brochure

Overview

Fast performance

Super-quick A4 print speeds of up to 45ppm

Great results

High-quality print capability

Flexible use

Great for shared workgroups, mobile printing

Eco features

Energy and cost-saving functions, high-capacity consumables



Model Order number Features
B512dn 45762026 Duplex, networked

Specifications

B512
Printing Method Digital LED Electrophotographic Printing Method
Printing Resolution 1200 x 1200 dpi
Warm-up Time Approx. 17.0 seconds from power-on
Approx. 17.0 seconds from power save
First Print Out Time Approx. 4.5 seconds
Print Speed A4 45 ppm
Interface 1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed), (Optional) Wireless LAN (IEEE802.11a/b/g/n)
Protocol TCP/IP
Printer Language PostScript 3 emulation, PCL 5e emulation, PCL 6 (XL) emulation, XPS emulation, IBM ProPrinter emulation, Epson FX Emulation, PDF v1.7 emulation
Supported OS (Click here for latest OS) Windows 8.1, Windows 8.1 x64, Windows 8, Windows 8 x64, Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, Windows Server 2003, Windows Server 2003 x64, OS X 10.9, OS X 10.8, OS X 10.7, Mac OS X 10.6, Linux
Memory (Std./Max.) 512MB/512MB
Font PostScript emulation 136 fonts, PCL emulation 87 scalable fonts, 4 bitmap fonts
Paper Size A4, A5, B5, A6, Letter, Legal 13, Legal 14, Executive, Statement, Envelopes, Custom Size: Width 86-216 mm x Length 140-1321 mm
Paper Weight Tray 1 : 60 – 120 gsm
(Optional)Additional Tray : 60 – 120 gsm
Multi-purpose tray : 60 – 160 gsm
Input Capacity Tray 1 : 530 sheets
(Optional)Additional Tray : 530 sheets
Multi-purpose tray : 100 sheets
Output Capacity Face Down : Max. 150 sheets
Face Up : Max. 100 sheets
Dimensions(WxDxH) 387 x 394 x 286 mm
Weight(includes supplies) Approx. 13.0 kg
Weight(not includes supplies) Approx. 12.0 kg
Operating Environment Operating: 10 – 32 °C, 20 – 80 %RH
No condensation
Power Source Single phase 230 VAC ±10%, 50/60 Hz ±2%
Power Consumption Operating: Max. 900W / Ave. 630W
Idle: 80W
Power Save: 7.0W
Deep Sleep: 1.4W
Auto-Off: 0.5W
Noise Level Operating :Approx. 56 dBA
Idle: < 30 dBA
Power Save: < 7 dBA or Background level
Quiet Mode: < 52 dBA
Duty Cycle Recommended: 5,500 pages/month
Maximum: 100,000 pages/month
In the Box Image Drum x 1, Starter toner cartridge x 1, DVD-ROM, Power cable, Ferrite Core
