General Information |
Original Size |
Max A3 |
Operation Panel |
Medium Office/Workgroup |
Standard Paper Capacity |
650 sheets (550-sheet x 1 + 100-sheet multi bypass) |
Maximum Paper Capacity |
Total 6,300 sheets (100-sheet Multi bypass + 550-sheets x 1) + Tandem Desk (550-sheets x 1, 1200 + 900 tandem) + LCC (3000 sheets) |
Paper Weight |
Tray: 60 g/m2 to 300 g/m2. Multi-bypass tray: 55 g/m2 to 300 g/m2 |
Output Capacity |
500 sheets: Opt: BP-TU10 400-sheets (lower) centre exit tray+ MX-TR20N 100-sheet (upper) job separator. |
Resolution (Output) |
Print: 1,200 x 1,200 dpi, 600 x 600 dpi, 9,600 (equivalent) x 600 dpi (depending on copy mode) |
Warm-up Time |
17 sec or less (Power Button) |
Resolution (Output) |
9,600 (equivalent) x 600 dpi (depending on Copy mode), 600 x 600 dpi |
Memory |
5GB (copy/print shared) |
HDD Capacity |
128GB SSD, Opt 512GB SSD |
Duplex |
Std. (60 – 105 g/m2) |
Dimensions (WxDxH) |
568 x 630 x 653 millimeter |
Weight |
79 kilogram |
Sharp OSA |
6.0 (Opt: BPAM10 and/or BPAM11 required) |
Copier Specification |
Copy Speed |
26ppm (A4), 15ppm (A3), 14ppm (SRA3) |
E-Sort / SOPM |
Yes / Yes |
Continuous Copy |
Max 9,999 |
Environmental |
Power Consumption |
Max. 1.84 kW |
TEC Value (Weekly) |
0.31 kWh |
Document Feeder |
Document Feeder |
Std. RSPF |
Original Capacity |
Max 100 sheets |
Scan Speed (Max) |
80 opm (1-sided) |
Document Filing |
Quick/Main Folder |
Quick/ Main/ Custom Folder: Max: 5,000 pages or 500 files (STD); Quick Folder: Max: 10,000 pages or 1,000 files Main/Custom: Max. 20,000 pages or 3,000 files with BP-SD10 (512GB SSD) |
Preview Thumbnails |
Supported (includes Advanced Edit Mode) |
Printer Specification |
Print Speed (Max) |
26ppm (A4), 15ppm (A3), 14ppm (SRA3) |
PDL (Emulation) |
STD: PCL6, Opt: Adobe® PostScript®3 [MXPK13] |
Interface |
USB 2.0 (host, high-speed), USB 3.0 (host, super speed), 10Base-T/100Base-TX/1000Base-T; Optional wireless LAN (IEEE 802.11 a/b/g/n/ac) |
Supported OS |
Windows® 8.1, Windows® 10, Windows® 11, Windows Server® 2012(R2), Windows Server® 2016, Windows Server® 2019, Windows Server® 2022; Mac OS® 10.10 to 10.15, 11, 12, 13 & 14 with Adobe® PostScript®3 [MX-PK13] |
Utility Software (Download) |
Status Monitor |
Sharpdesk Mobile |
Supported |
Utility Software (Download) |
NST-Lite |
Sharpdesk Mobile |
Supported (via Wireless Access Point or MXEB18) |
Airprint Support |
Opt: MXPK13 required |
Pantone Support |
N/A |
Network Scanner |
Resolution |
Push scan: 100, 150, 200, 300, 400, 600 dpi; Pull scan 75, 100, 150, 200, 300, 400, 600 dpi (50 to 9,600 dpi via user setting) |
Format |
TIFF, XPS, JPEG*, PDF, Encrypted PDF; Opt: Compact PDF* with MXEB19; Opt: Office Format (docx, xlsx, pptx), PDF/A-1a, PDF/A-1b, Searchable PDF, TXT, RTF & UTF-8 with MXEB20. (*colour/greyscale only) |
Destination |
Desktop (NST-Lite), FTP, E-Mail, SMB Folder, USB, HDD, TWAIN / WIA compliant, I-Fax (SMTP) |
User Registration |
Max 2,000 registrations (Max. 500 addresses for one Group Key) |
Utility Software (Download) |
NST Lite |
Cloud Connectivity |
Requirement |
Optional BPAM10 is required |
Cloud Connectors |
Microsoft® One Drive® for Business, Microsoft® SharePoint® Online, Microsoft® Teams®, Google Drive™, Box™ & Dropbox™ |
Email Connectors |
Microsoft® Exchange (Online) & Google Gmail™ |
Microsoft Universal Print |
Supported |
Sharp Application Cloud Portal |
Supported |
Fascimillie |
Facsimile Model |
Opt : BPFX11 |
Communication Protocol |
Super G3/ G3 |
Compression |
MH, MR, MMR, JBIG |
Inbound Routing |
Yes (PDF, Single TIFF, Multi TIFF, XPS) to E-mail, FTP, SMB, Desktop, Fax & I-Fax. |
PC Fax |
Yes (For Windows only) |
