General Information |
Operation Panel |
Colour 10.1″ LCD Touch-Screen |
Product Environment |
Departmental |
Printed Paper Size |
Tray: A3W – A5R, Bypass: 13 x 19.2 – A5R |
Standard Paper Capacity |
3,100 (1200-sheets, 800 sheets, 500 sheets x 2, 100-sheet Multi bypass) |
Maximum Paper Capacity |
8,500 (5,000 sheets LCT, 1,200 sheets, 800 sheets, 500 sheets x 2, 500 sheets) |
Paper Weight |
Tray 1 & 2: 60-105gsm, Tray 3 & 4: 60-300gsm, LCC: 60-220gsm, LCT (Air): 55-300gsm, Bypass Tray: 55-300gsm (STD), 55-220gsm [MX-MF11] |
Output Capacity |
Optional MXTU14 250-sheet centre tray or Finisher is required, additional MXTR14 100-sheet right tray |
Resolution (Output) |
Print: 1,200 x 1,200 dpi, 600 x 600 dpi, 9,600 (equivalent) x 600 dpi (depending on copy mode) |
Memory |
6 GB (STD & Max) |
HDD Capacity |
1TB |
Duplex |
Std. (60 – 300 g/m2) |
Dimensions (WxDxH) |
845 x 844 x 1,249 millimetre |
Weight |
209 kilogram |
Sharp OSA |
5.5 (Opt: MXAMX2 and/or MXAMX3 required) |
Copier Specification |
Copy Speed |
70 ppm (A4 Colour), 75 ppm (A4 B&W), 34ppm (A3) |
E-Sort / SOPM |
Yes / Yes |
First Copy Time (OC) |
Colour: 5.6 sec, B/W: 4.0 sec |
Continuous Copy |
Max 9,999 |
Scan Resolution |
Colour: 600 x 600 dpi; B/W: 600 x 400 dpi, 600 x 600 dpi |
Zoom Range |
25 – 400% (DSPF 25 – 200%) in 1% increments |
Environmental |
Power Consumption |
Max. 3.84 kW |
TEC Value (Weekly) |
6.5 kWh |
Document Feeder |
Document Feeder |
Std. RSPF |
Original Capacity |
Max 300 sheets (80 g/m2) |
Scan Speed (Max) |
120 opm (1-sided), 240 opm (2-sided) |
Double Feed Detection |
Standard |
Document Filing |
Quick/Main Folder |
Quick Folder: Max 10,000 pages, Main/Custom Folder: Max 35,000 pages or 5,000 files |
Preview Thumbnails |
Supported (includes Advanced Edit Mode) |
Printer Specification |
Print Speed (Max) |
70 ppm (A4 Colour), 75 ppm (A4 B&W), 34ppm (A3) |
PDL (Emulation) |
STD: PCL6 emulation, Adobe® PostScript® 3™ |
Interface |
USB 2.0, 10Base-T/100Base-TX/1000Base-T |
Fiery Controller |
Optional MXPE15 (embedded controller) |
Protocol |
TCP/IP (IPv4, IPv6), |
Utility Software (Download) |
Status Monitor |
Sharpdesk Mobile |
Supported |
Airprint Support |
Supported |
Pantone Support |
Supported |
Network Scanner |
Resolution |
Push scan: 100, 150, 200, 300, 400, 600 dpi; Pull scan 75, 100, 150, 200, 300, 400, 600 dpi (50 to 9,600 dpi via user setting) |
Format |
TIFF, JPEG (colour/greyscale only), XPS, PDF, PDF/A, Encrypted PDF, Searchable PDF, Compact PDF, Office Format (docx, xlsx, pptx), TXT, RTF & UTF-8. |
User Registration |
Max 2,000 registrations (Max. 500 addresses for one Group Key) |
Utility Software (Download) |
NST Lite |
Cloud Connectivity |
Requirement |
Optional MXAMX2 is required |
Cloud Connectors |
Microsoft® One Drive® for Business, Microsoft® SharePoint® Online, Google Drive™, Box™ & Dropbox™ |
Email Connectors |
Microsoft® Exchange (Online) & Google Gmail™ |
Microsoft Universal Print |
Not supported |
Sharp Application Cloud Portal |
Supported |
Fascimillie |
Facsimile Model |
Opt : MXFX15 |
Communication Protocol |
Super G3/ G3 |
Compression |
MH,MR,MMR,JBIG |
Inbound Routing |
Yes (PDF, Single TIFF, Multi TIFF, XPS) to E-mail, FTP, SMB, Desktop, Fax & I-Fax. |
PC Fax |
Yes (For Windows only) |
